Model No.MCD-SMD-3528-4.8-60-IP20/IP67 DC12V/24V

Input Voltage (V) DC12V/DC24V
LED Power (W) 4.8W/1m
System Power (W)
Luminous Flux:346m(White) 300lm(Warm White)
Beam Angle(°) 120
Color Temp:2800K~7000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):幅8mm
Weight(Kg):
IP-protectino:IP20/IP65/IP67
制作可能色:White/Warm White/red/green/blue
yellow/RGB
unit 切断寸法:12V 3LED 24V 6LED
LEDs/m:60
LED間隔:16.7mm

Model No.MCD-SMD-5050-6.6-30-IP20/IP67 DC12V/24V

Input Voltage (V) DC12V/DC24V
LED Power (W) 6.6W/1m
System Power (W)
Luminous Flux:480m(White) 422lm(Warm White)
Beam Angle(°) 120
Color Temp:2800K~7000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):幅10mm
Weight(Kg):
IP-protectino:IP20/IP65/IP67
制作可能色:White/Warm White/red/green/blue
yellow/RGB
unit 切断寸法:12V 3LED 24V 6LED
LEDs/m:60
LED間隔:33.3mm

Model No.MCD-SMD-3528-8.8-120-IP20/IP67 DC12V/24V

Input Voltage (V) DC12V/DC24V
LED Power (W) 8.8W/1m
System Power (W)
Luminous Flux:670m(White) 600lm(Warm White)
Beam Angle(°) 120
Color Temp:2800K~7000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):幅10mm
Weight(Kg):
IP-protectino:IP20/IP65/IP67
制作可能色:White/Warm White/red/green/blue
yellow/RGB
unit 切断寸法:12V 3LED 24V 6LED
LEDs/m:120
LED間隔: mm

Model No.MCD-SMD-5050-13.2-60-IP20/IP67 DC12V/24V

Input Voltage (V) DC12V/DC24V
LED Power (W) 13.2W/1m
System Power (W)
Luminous Flux:1080m(White) 898lm(Warm White)
Beam Angle(°) 120
Color Temp:2800K~7000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):幅10mm
Weight(Kg):
IP-protectino:IP20/IP65/IP67
制作可能色:White/Warm White/red/green/blue
yellow/RGB
unit 切断寸法:12V 3LED 24V 6LED
LEDs/m:60
LED間隔:16.7mm

Model No.MCD-SMD-5050-17.6-60-IP20/IP67 DC12V/24V

Input Voltage (V) DC12V/DC24V
LED Power (W) 13.2W/1m
System Power (W)
Luminous Flux:1385m(White) 1200lm(Warm White)
Beam Angle(°) 120
Color Temp:2800K~7000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):幅10mm
Weight(Kg):
IP-protectino:IP20/IP65/IP67
制作可能色:White/Warm White/red/green/blue
yellow/RGB
unit 切断寸法:12V 6LED 24V 12LED
LEDs/m:60
LED間隔:mm

Model No.MCD-SMD-5050-26.4-120-IP20/IP67 DC12V/24V

Input Voltage (V) DC12V/DC24V
LED Power (W) 26.4W/1m
System Power (W)
Luminous Flux:2070m(White) 1800lm(Warm White)
Beam Angle(°) 120
Color Temp:2800K~7000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):幅28mm
Weight(Kg):
IP-protectino:IP20/IP65/IP67
制作可能色:White/Warm White/red/green/blue
yellow/RGB
unit 切断寸法:12V LED 24V LED
LEDs/m:120
LED間隔:mm

Model No.MCD-SMD-3528-26.4-360-IP20/IP67 DC12V/24V

Input Voltage (V) DC12V/DC24V
LED Power (W) 26.4W/1m
System Power (W)
Luminous Flux:1953m(White) 1690lm(Warm White)
Beam Angle(°) 120
Color Temp:2800K~7000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):幅 mm
Weight(Kg):
IP-protectino:IP20/IP65/IP67
制作可能色:White/Warm White/red/green/blue
yellow/RGB
unit 切断寸法:12V LED 24V LED
LEDs/m:360
LED間隔:mm

Model No.MCD-SMD-5050-30-XY AC100V

Input Voltage (V) AC100V
LED Power (W) 12W/1m
System Power (W)
Luminous Flux:350lm(White) lm(Warm White)
Beam Angle(°) 120
Color Temp:2800K~7000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):幅 14mm
Weight(Kg):
IP-protectino:IP44
制作可能色:White/Warm White/red/green/blue
yellow/RGB
unit 切断寸法:500mm
LEDs/m:30
LED間隔:mm
50m roll

Model No.MCD-SMD-3528-60-XY AC100V

Input Voltage (V) AC100V
LED Power (W) 4W/1m
System Power (W)
Luminous Flux:300lm(White) lm(Warm White)
Beam Angle(°) 120
Color Temp:2800K~7000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):幅 11mm
Weight(Kg):
IP-protectino:IP65
制作可能色:White/Warm White/red/green/blue
yellow/RGB
unit 切断寸法:1000mm
LEDs/m:60
LED間隔:mm
50m/100m roll

Model No.MCD-SMD-3528-60-XY AC100V Power Supply

Waterproof Power Supply

Model No.MCD-SMD-5050-30-XY AC100V Power Supply

Waterproof Power Supply

Model No.MCD-RGB

Model No.MCD-100-240V
